Pillar Jib Cranes Introduction

The pillar jib crane is a new generation of light-duty hoisting equipment made to adapt to modern production. It is especially suitable for short-distance, frequent-use, and intensive hoisting operations when combined with high-reliability electric chain hoists. It has high efficiency, energy saving, and trouble-saving. Small area, easy to operate and maintain. In operation, the jib swings through an arc to provide additional lateral movement. And the jib of the crane is a hollow steel structure, with light weight, large span, large lifting capacity, economical and durable.

The pillar mounted jib cranes are one of the most practical lifting and transfer solutions in the industry. Besides, pillar mounted jib cranes are used both in industry for the handling of low-tonnage loads, as well as for yachts and for unloading on seaside and shore.
European-style jib crane is a medium-sized lifting equipment developed in recent years. It has a unique structure, is safe and reliable, and has the characteristics of high efficiency, energy saving, time-saving, labor-saving, and flexibility. It can be operated freely in three-dimensional space. Other conventional lifting equipment shows its superiority.mes used to move hydroelectric gates.

Specification

Product Specifications

Load capacity:

1ton ~16 tons

Crane span:

2m ~12m or customized

Lifting height:

2m to 12m or customized

Hoist unit:

Wire rope hoist or chain hoist

Working duty:

Power source:

Based on your power supply

Process Crane Features

Design

Technology

Production

Maintenance And Security

All types of process cranes produced by us are manufactured in a modular manner, with a high degree of standardization and high replaceability of components.

The steel structure design of the crane bridge meets the convenience and possibility of manufacturing, inspection, transportation, installation and maintenance.

Deflection is calculated at a rate of at least 1/1000 in the double girder bridge structures used in our custom manufactured craft cranes, and our bridges do not exceed a maximum deflection of 3mm.

industrial shaft process cranes for sale

Design Scheme

SEVENCRANE stands for first-rate service, cost-effective, high quality.

Some types of process cranes, such as metallurgical cranes, use thermal shields to protect the building from the heat as needed. Choose the mechanism based on the desired lifting and execution speed and job class.

Process cranes are designed in the strongest and lightest possible way and are built to DIN norms and FEM standards.

Our process cranes are the guarantee for your construction, installation, production and loading and unloading operations, and are also important equipment to improve the economic benefits of enterprises.

The new range of cranes offers robust, intelligently designed modules that can be easily configured to suit a variety of needs. With this type of crane technology, users can change or add new features over time according to business needs.

In main lifts, auxiliary lifts, trolley travel, and bridge travel systems, frequency converter drives are used to provide jerk-free motion and minimal load sway.

In the application, it can handle the positioning of process cranes, x-y-z axis positioning, automatic stop-and-go movement in any direction, working time detection, power consumption, fault detection, remote intervention on certain faults, etc.

According to the working environment, suitable motors, forced fans, electric room air conditioners and control cabinets can be selected. It is stopped by electro-hydraulic brakes.

industrial transfer trolleys manufacturer

Technology

Other functions include remote diagnostics, maintenance monitoring or automatic positioning. This type of crane technology can scale with the business, allowing companies to be more flexible and achieve a greater return on investment.

Special manufacturing processes require tailor-made solutions. A skilled company, fully familiar with the tasks and circumstances of the industry.

Emergency stop safety brakes can also be used according to tonnage and needs. With the emergency stop safety brake, the safety of machines and workers can be effectively guaranteed.

SEVENCRANE, planned and built as a "means of production individual of the customer's processes", has the highest expectations. We will do our best to meet the specific needs of each customer.

Production

SEVENCRANE stands for first-rate service, cost-effective, high quality.

We have a complete production line for decoiling, leveling, shearing, shot blasting, painting, and drying pretreatment.

Welds of bridge beams produced using quality-certified sheet metal adopt non-destructive testing methods, and dimensions are controlled in accordance with TS-EN-1090 tolerances.

All outsourced bridge frames are welded with submerged arc welding robots. In the production of crane bridges, sandblasting and painting are carried out according to world standards.

Special paint applications can be made taking into account the working conditions of the crane. We can spray special colors according to customers' requirements.

For crane systems in special fabrication, we have radio frequency remote control and in-cabin control options.

Every production link will be inspected by the quality control department and a certificate of conformity will be provided.

industrial container cranes with ce certificate

MAINTENANCE AND SECURITY

All operators in our production workshop must hold legal operating certificates.

We will provide a standard maintenance platform for each set of cranes, which is convenient for maintenance personnel to inspect and maintain the cranes.

Operators have received professional training before working with certificates to understand the structure, performance, operation methods and safety matters of European cranes.

All our production indicators and technologies are aimed at ensuring the safe and stable operation of European cranes, preventing accidents caused by human factors, and ensuring the safety of personnel and property.

Safety protection devices, such as limit switches, overload limiters, PTC thermistors, collision sensors and emergency stop buttons, ensure the stability and safety of the crane during operation.

We can guarantee you high quality crane products with minimum wear and maintenance.

We will equip all the cranes with load cells and load switches to minimize production accidents for your project.
