Principio de funcionamiento y características de la grúa giratoria montada en la pared

A wall-mounted jib crane, also known as a wall-mounted swing arm crane or wall-mounted cantilever crane, is a type of lifting equipment that is fixed to a wall or vertical surface. It is designed to provide a lifting and handling solution for materials and loads in industrial environments. Here is an introduction to wall-mounted jib cranes:

Structure: A grúa giratoria montada en la pared typically consists of the following components:

1. Wall Bracket: The wall bracket serves as the support structure and is securely attached to a wall or vertical surface. It provides stability and rigidity to the crane system.
2. Jib Arm: The jib arm, also called the boom or cantilever, extends horizontally from the wall bracket. It is the primary component responsible for supporting the lifting mechanism and allows the crane to rotate or swing in a specific arc.
3. Lifting Mechanism: The lifting mechanism can vary depending on the specific requirements and load capacities of the crane. It may include a hoist, electric chain or wire rope hoist, or other lifting devices capable of raising and lowering loads.
4. Rotation System: Wall-mounted jib cranes are designed to rotate around a vertical axis. They can either have a manual rotation system that requires manual effort to rotate the crane or a motorized rotation system that allows for smoother and more effortless rotation.

Benefits and Applications of SEVENCRANE wall mounted jib crane:

1. Space-Saving: Wall-mounted jib cranes are ideal for areas with limited floor space. By mounting the crane on a wall, it frees up valuable floor space for other operations and equipment.
2. Flexibility: The jib arm of a wall-mounted crane can rotate up to 180 degrees or even a full 360 degrees, depending on the design. This provides flexibility in positioning and moving loads within the working area.
3. Increased Efficiency: Wall-mounted jib cranes enable efficient and ergonomic material handling. They can be positioned near workstations or machinery, reducing the time and effort required to move loads manually.
4. Versatility: These cranes can be customized to suit various industrial applications, including warehouses, manufacturing facilities, assembly lines, loading docks, and maintenance areas. They can be used for lifting and moving a wide range of materials, such as components, parts, tools, and machinery.
5. Cost-Effective: Compared to larger overhead cranes, wall-mounted jib cranes are often more cost-effective in terms of initial investment, installation, and maintenance.

Working principle of wall mounted jib crane:

1. Structure: Wall-type cantilever crane consists of wall bracket, cantilever arm, lifting mechanism and control system.

2. Installation: The wall bracket is fixed on the wall, and the cantilever arm is connected to the wall bracket through the connecting arm base to form a suspended structure.

3. Lifting mechanism: The lifting mechanism usually consists of an electric hoist or an electric chain lifting mechanism, through which heavy objects can be lifted and suspended.

4. Control system: Wall-mounted jib cranes are usually equipped with a control system to control the operation of the lifting mechanism, including operations such as lifting, moving and stopping.

Wall mounted jib crane working features:

1. Space utilization: Wall-mounted cantilever cranes can be installed on the wall to make full use of the space in the work area and reduce the occupation of floor space.

2. Flexibility: The cantilever arm can rotate or swing on the wall bracket, allowing the lifting object to move horizontally and vertically along the wall, providing a flexible operating range.

3. Easy installation: Compared with other lifting equipment, the installation of wall-mounted cantilever cranes is relatively simple. It does not require an independent support structure and only needs to be fixedly installed on the wall.

4. Lifting capacity: The wall-mounted cantilever crane can choose the appropriate lifting mechanism according to needs. It has strong lifting capacity and can adapt to the needs of different working scenes.

5. Easy maintenance: The maintenance of workshop used grúa giratoria montada en la pared is relatively simple, and daily maintenance and inspection are more convenient, which can reduce downtime and maintenance costs.

It should be noted that the working principles and characteristics of factory direct sale wall mounted jib crane are generally described, and the specific design and application may vary depending on the wall mounted jib crane manufacturer and usage scenarios. In actual use, a suitable wall-mounted jib crane should be selected according to the specific situation, and operated and maintained in accordance with the operating manual and safety regulations provided by the manufacturer.
